Mine Tailing Sewage Filter Press Filter Cloth Polypropylene Filter Fabrics

Mine Tailing Sewage Filter Press Filter Cloth Polypropylene Filter Fabrics

Product Details:

Place of Origin: CHINA
Brand Name: ECOGRACE
Certification: ISO / 9001 , SGS
Model Number: 1600 mmx 1600 mm

Payment & Shipping Terms:

Minimum Order Quantity: 50 sets
Price: 10 -50 USD / PCS
Packaging Details: Polybags with pallets
Delivery Time: 2-6 WEEKS
Payment Terms: Western Union, MoneyGram, L/C, T/T, D/A, D/P
Supply Ability: 2000 sets / day
Contact Now
Detailed Product Description

Detailed Product Description

Filter Cloth:Filter Press ClothApplication:Mine Tailing Sewage
Yarn/ Filament:220-650 GSMSize:1600 X 1600mm
Feature:Polypropylene Filter Fabrics

Mine Tailing Sewage Filter Press Filter Cloth Polypropylene Filter Fabrics

ECOGRACE Filter Cloth Liquid Solid Separation Filter Cloth is mainly applied for Mining industry , Chemical Industry, Food industry. Mineral tailing concentration,  Wastewater treatment , sludge sewage dewatering, kaolin clay , quarry , granite production process,etc.

ECOGRACE Filter Cloth Liquid Solid Separation Filter Cloth is mainly applied for Mining industry , Chemical Industry, Food industry. Mineral tailing concentration, Wastewater treatment , sludge sewage dewatering, kaolin clay , quarry , granite production process,etc.

Mining Industry Filter Press Cloth Dry Cake Clear Filtration 1500x1500mm

Filter press is increasingly applied by more and more industries such as Metallurgy, Mining, Printing as an effective and affordable equipment of solid-liquid separation. As an essential factor of filter press, filter cloth plays an important role to ensure clear filtration, dry filter cake and short filter cycle.

Filter cloth selection mainly depends on

  • Materials.
  • Yarn Types.
  • Weave Patterns.

Materials:

Polypropylene Filter fabric:

Polypropylene Filter fabric is characterized by sleekness, excellent permeability and nil moisture absorption. Its excellent cake release will significantly shorten cleaning time as well as filter cycle. It also has excellent resistances against most acids and alkalis. Its constant working temperature is rated at 280 °F.

Nylon filter cloth:

Nylon filter cloth features optimum abrasive resistance and strong alkali resistance. It is often found in miner and coal industries for its best abrasion proof. The only shortage is that its chemical instability under high temperature when it will release toxic substance and pollute the solutions. So, nylon filter cloth is not accepted by food & beverage and pharmaceutical.

Polyester (PE) filter cloth:

The prominent property for polyester fabric is its strongest acid resistance among existing synthetic fabrics. It is widely recognized as an outstanding and popular filter cloth for its high operating temperature up to 302 °F, high tensile strength and good elongation.

Vinylon filter cloth:

Thanks to its strongest alkali resistance, vinylon filter cloth is suitable for caustic condition. Its working temperature is less than 140 °F.

Properties of Frequently Used Filter Fabrics
Property Polyester (PE) Polypropylene Vinylon
Acid Excellent Excellent Poor
Alkali Average Excellent Excellent
Electrical Conductivity Poor Good Average
Elongation 30%-40% Better than PE 12%-25%
Recovery Excellent Slightly better than PE Poor
Abrasion Excellent Good Excellent
Heat Resistance 170 °C 90 °C 100 °C
Softening point 230 -240 °C 140 -150 °C 200 °C
Melting point 255 -265 °C 165 -170 °C 220 °C

ECOGRACE Filter Cloth :

Filter Cloth For plate filter press , Belt Filter Press , Disc Filter , etc.
a. Filter Cloth : Polyester Filter Cloth , Polypropylene Filter Cloth , PA Filter Cloth ,
b. Weight standard: 250g / sqm – 900 g / sqm . Make to order is also accepted.
c. Polyester Monofilament Filter Cloth are widely applid in sugar plant and iron ore industry filter press .

d. Non woven felt filter cloth , 600- 800 gsm weight.

Filter Cloth Material :
Polyester(Terylene/PET) Filter Cloth.
Polypropylene (PP) Filter Cloth ,
Chinlon (polyamide/nylon) Filter Cloth
Vinylon PV Filter Cloth .

Needle felt

Cotton.

Filter Cloth Application :
Mining Industry :Coal Washing , Tailing of Gold / Zinc / Nickle , Tialing of coal, Kaolin clay, Cement , Aggregate , Asphalt , etc.

Environmental protection: Sewage treatment, Sludge dewatering , flue gas desulphurization, Salt mud , fly ash, etc.


Chemical Industry :Pigment , Zinc oxide, Activated carbon, , Iron oxide , Nickle, Titanium Oxide, White Carbon Black , Calcium Carbonate , etc.

Steel & Iron ,Metallurgical Industry :Alumina / Aluminum oxide , Iron Ore , Gold, Leads , Vanadium , Nickel , Zinc , Copper, Titanium, etc.

Food processing :Fruit juice, Sugar, Syrup,Beer Eatable Oil , etc.


Filter Cloth Choosing :

P0802Y Coal Washing
T0803t Waste Water treatment
P050D, P030MD, P020MD Mud / Slurry Dewatering
N9029 Alumina / Aluminim Oxide
N199 Iron ore concentrate
P1010 Aggregate / Mining
P020MD Leads ore concentrate
9501-35 Cement Plant
9501-34 Zinc oxide
PT9502b-41DY Municiple Water / Waste water treatment
PT9502b-31 Gold
P750AB Copper
9502-402DY Slurry Dewatering
P190 Beer filtration
P199s/P11636: Sugar Plant filtration
N120B Palm oil filtration,
3233SY White carbon black
3233SY/108C/P801IIy Kaolin Clay
T3112BY/3233SYY Pigment, dyestuff


Advantage OF ECOGRACE Filter Press Cloth :
High dimensional stability,
Good abrasion performance,
Wide range of filter rate
Efficient fabric cleaning
Smooth Surface
Easy Cake Releasing .

Mine Tailing Sewage Filter Press Filter Cloth Polypropylene Filter Fabrics
