Place of Origin: | CHINA |
Brand Name: | ECOGRACE |
Certification: | ISO / 9001 , SGS |
Model Number: | Polypropylene filter cloth |
Minimum Order Quantity: | 50 sets |
---|---|
Price: | 10 -50 USD / PCS |
Packaging Details: | Polybags with pallets |
Delivery Time: | 2-6 WEEKS |
Payment Terms: | D/P, L/C, T/T, Western Union, D/A, D/P |
Supply Ability: | 2000 sets / day |
Detailed Product Description
Filter Cloth: | PP Filter Cloth | Weaving: | Double Weave |
---|---|---|---|
Yarn/ Filament: | Monofilament | Application: | Mining , Slurry Dewatering ,Coal Washing , Alumina , |
Weight: | 300-500 GSM , 1000GSM |
30 Micron Filter Cloth PP Filter Cloth Polypropylene Filter Press Cloth
ECOGRACE Filter Cloth
a. Filter Cloth : Polyester Filter Cloth , Polypropylene Filter Cloth , PA Filter Cloth , Nylon Filter Cloth .
b. Working temperature: normal working temperature 88 degree C , 110 Degree C peak working temperature.
c. Weight standard: 250g / sqm – 500g / sqm . Make to order is also accepted.
d. PA Nylon Filter Cloth , Monofilament Filter Cloth . Singel Layer , Double Layer
Filter press cloth normally include 4 types,
Polyester(Terylene/PET) Filter Cloth.
Polypropylene (PP) Filter Cloth ,
Nylon Filter Cloth
Chinlon (polyamide/nylon) Filter Cloth
Vinylon PV Filter Cloth .
Polypropylene filter cloth
There are 3 series of Polypropylene/PP filter cloth:
1. PP multifilament (long thread) filter cloth
2. PP monofilament filter cloth
3. PP multifilament/monofilament filter cloth
Applications
Separation in solid and liquid to equip with filter press ,conveyor belts filtration Machine ,Filter Leaf ,Horizontal Rotating Pan Filter ,Vacuum filter ,in Chemical industry ,Fertilizer industry ,Sugar making ,food and beverage ,metallurgy ,Building ,Waste water dealing and so on .
Filter Cloth Application :
Mining Industry :
Coal Washing , Tailing of Gold / Zinc / Nickle , Tialing of coal, Kaolin clay, Cement , Aggregate , Asphalt , etc.
Steel & Iron ,Metallurgical Industry :Alumina / Aluminum oxide , Iron Ore , Gold, Leads , Vanadium , Nickel , Zinc , Copper, Titanium, etc.
Food processing :
Fruit juice, Sugar, starch , sweetener, Beer Eatable Oil , etc.
Filter Cloth Choosing :
P0802Y | Coal Washing |
T0803t | Waste Water treatment |
P050D, P030MD, P020MD | Mud / Slurry Dewatering |
N9029 | Alumina / Aluminim Oxide |
N199 | Iron ore concentrate |
P1010 | Aggregate / Mining |
P020MD | Leads ore concentrate |
9501-35 | Cement Plant |
9501-34 | Zinc oxide |
PT9502b-41DY | Municiple Water / Waste water treatment |
PT9502b-31 | Gold |
P750AB | Copper |
9502-402DY | Slurry Dewatering |
P190 | Beer filtration |
P199s/P11636: | Sugar Plant filtration |
N120B | Palm oil filtration, |
3233SY | White carbon black |
3233SY/108C/P801IIy | Kaolin Clay |
T3112BY/3233SYY | Pigment, dyestuff |
